Cable protection | 3 x ø65mm

Industrial Rubber Cable Protector with 3 Channels 65 × 65 mm – 20 Ton Axle Load Capacity

Maximum protection for large-diameter industrial cables

This ultra-heavy-duty rubber cable protector is specifically designed to protect very large-diameter cables in demanding environments such as industrial zones, logistics platforms, heavy construction sites, event stages, or areas with frequent heavy vehicle traffic.

Equipped with three wide channels (65 × 65 mm), a reinforced polypropylene lid, and heavy-duty hinges, this cable protector offers exceptional durability and easy installation even under intensive use conditions.

Its dovetail interlocking system ensures secure connections between multiple modules, while the integrated carrying handle allows easy handling during installation. Optional 30° corner sections and end caps are available to create customized cable routing configurations adapted to your site layout.

Key advantages of the CP1071 by VISO

Extreme load resistance: up to 20 tons per axle

Three extra-wide channels 65 × 65 mm, suitable for hydraulic, power, and heavy data cables

Heavy-duty hinges for durable and smooth opening

Dovetail connectors for secure and modular installation

Integrated carrying handle for easy transport

Compatible with 30° corner sections and end caps (optional accessories)

Technical specifications – CP1071

Length: 910 mm

Width: 500 mm

Height: 81 mm

Number of channels: 3

Channel dimensions: 65 × 65 mm

Materials:

– Rubber body

– Reinforced polypropylene lid

Opening system: Top-loading with heavy-duty hinges

Load capacity: Up to 20 tons per axle

Modular connection: Dovetail interlocking system

Available accessories: 30° corner sections and end caps (sold separately)

Integrated handle: Yes

FAQ – CP1071 3-channel cable protector

Is this cable protector suitable for heavy trucks?

Yes. With a load capacity of up to 20 tons per axle, it is designed for heavy-duty traffic including trucks, forklifts, and construction equipment.

What cable sizes can it accommodate?

It can hold three cables up to 65 mm in diameter, making it ideal for power, hydraulic, or multi-conductor cables.

Can a full cable route be created with corners?

Yes. The model is compatible with 30° corner sections and end caps, allowing flexible installation depending on the site layout.

Is the lid easy to open?

Yes. The reinforced hinges allow smooth opening while maintaining excellent long-term durability.

Do the modules stay firmly connected?

Yes. The dovetail interlocking system ensures a stable connection between modules, even on uneven surfaces.
