Heavy duty cable protection | ø50/80/120mm

Heavy-Duty Outdoor Cable Protector for Trucks – Ø50 to Ø120 mm

The heavy-duty outdoor cable protector is specifically designed to protect very large-diameter cables in areas exposed to intense traffic. Made entirely from high-density rubber, it provides a robust and durable solution for securing electrical or technical installations in demanding professional environments.

This model is particularly suited for logistics zones, construction sites, industrial facilities, outdoor events, and public roads where trucks or handling equipment circulate regularly. It effectively protects cables laid on the ground while ensuring safe and smooth passage for both vehicles and pedestrians.

The bottom-loading system allows cables to be installed quickly without opening a lid, making installation faster and easier. This design is ideal for temporary installations or situations requiring rapid deployment.

Available with one or two channels, this cable protector can accommodate cables with diameters of Ø50 mm, Ø80 mm, or Ø120 mm, making it suitable for large power cables and high-capacity industrial networks.

To improve safety and visibility—especially at night or in poorly lit areas—the unit includes high-visibility reflectors, consisting of four integrated reflectors and two lateral reflective “shark teeth” elements (3M Class 3).

With a load capacity of up to 40 tons, this cable protector allows trucks, utility vehicles, and construction machinery to pass safely while ensuring the cables remain fully protected.

Technical specifications

Number of channels: 1 or 2

Accepted cable diameters: Ø50 mm / Ø80 mm / Ø120 mm

Loading system: Bottom loading

Material: 100% high-density rubber

Load capacity: Up to 40 tons

Reflectors:

• 4 integrated night reflectors

• 2 lateral reflective shark-tooth elements (3M Class 3)

Surface: Anti-slip

Use: Indoor and outdoor applications

Applications: Construction sites, logistics zones, industrial facilities, events, public roads

FAQ – Heavy-duty outdoor cable protector

What is a truck-rated cable protector used for?

It protects large-diameter cables placed on the ground from crushing while ensuring safe circulation for heavy vehicles and pedestrians.

What cable diameters can it accommodate?

This model supports cables with diameters of 50 mm, 80 mm, or 120 mm, depending on the chosen configuration.

Why choose a bottom-loading design?

Bottom loading allows quick installation without opening a lid, making it particularly practical for temporary setups.

Is it visible at night?

Yes. It includes high-visibility reflectors and 3M Class 3 reflective shark-tooth markings, ensuring excellent nighttime visibility.

Can it withstand heavy truck traffic?

Yes. Its high-density rubber construction supports loads up to 40 tons, allowing trucks and heavy machinery to pass safely.

Can it be used outdoors?

Yes. It is designed to withstand weather conditions, UV exposure, and intensive professional use.
