Rubber cable protection | 6 x ø34mm

Industrial Rubber Cable Protector with 6 Channels 25 × 34 mm – Load Capacity up to 20 Tons per Axle

The CP1006 industrial cable protector is designed to provide reliable and long-lasting protection for cables in high-traffic professional environments. Its high-density rubber structure combined with a reinforced top-loading lid ensures effective protection of electrical installations and network cables while allowing easy installation and maintenance.

This model is particularly suited for high-traffic areas such as construction sites, logistics warehouses, events, trade shows, and industrial zones. With a load capacity of up to 20 tons per axle, it can withstand the passage of utility vehicles and handling equipment while protecting cables from crushing and wear.

The protector features six channels measuring 25 × 34 mm, allowing several medium-sized cables to pass through simultaneously, including power cables, audio cables, or data network lines. The hinged lid with heavy-duty hingesensures long-term durability and quick access to cables when maintenance is required.

A dovetail interlocking system allows multiple modules to be connected together, creating a continuous and perfectly aligned cable protection route over long distances. An integrated carrying handle simplifies transport and positioning during installation.

To adapt to different site configurations, this model is compatible with 30° corner sections and end caps, available as optional accessories.

Technical specifications

Length: 910 mm

Width: 500 mm

Height: 48 mm

Number of channels: 6

Channel dimensions: 25 × 34 mm

Material: High-density rubber

Loading system: Top loading

Hinges: Heavy-duty reinforced hinges

Carrying handle: Integrated

Connection system: Dovetail interlocking

Load capacity: Up to 20 tons per axle

Compatible accessories: 30° corner sections and end caps (optional)

Applications: Construction sites, events, logistics warehouses, industrial environments

FAQ – CP1006 industrial cable protector

What is an industrial cable protector used for?

It protects cables laid on the ground from impacts and crushing while ensuring safe movement for pedestrians and vehicles.

How many cables can it accommodate?

This model includes six channels measuring 25 × 34 mm, allowing several medium-sized cables to pass through simultaneously.

Can multiple modules be connected together?

Yes. The dovetail interlocking system allows several cable protectors to be assembled together to cover long distances.

Is it suitable for vehicle traffic?

Yes. It supports loads of up to 20 tons per axle, making it suitable for professional traffic areas.

Can it be used outdoors?

Yes. The high-density rubber construction is resistant to weather, UV exposure, and temperature variations, making it suitable for both indoor and outdoor use.
